Cable Management System Sizing

Proper cable management is essential for any professional electrical installation. Voltnet Engineering provides comprehensive CAD-based cable management system sizing services, ensuring your cable trays, trunking, and conduit systems are correctly sized for current and future requirements.

Our engineers use advanced CAD software to design cable containment systems that comply with BS 7671 spacing requirements, support proper heat dissipation, and allow for maintenance access. We consider factors like cable fill ratios, bend radii, and support spacing to create efficient, compliant designs.

Our Cable Management Services

We design and size cable tray systems (ladder, perforated, and solid bottom), cable trunking (PVC and metal), conduit systems, floor boxes and underfloor systems, and vertical risers for multi-storey buildings.

Future-Proofing Your Installation

We always design with expansion in mind, typically including 25-30% spare capacity to accommodate future additions without costly modifications. This forward-thinking approach saves money in the long run.
